Description of the product
Electronic protractor designed to quickly and accurately measure the angle between two planes . Particularly useful when setting machines, e.g. the angle of the disc in table saws. The device has a large, clear, backlit display . The HOLD function allows you to keep the current measurement on the display. The REF function allows you to zero the protractor at any position and perform a reference measurement. The meter is equipped with a magnet placed in the base, which makes it much easier to perform measurements on steel elements.
Characteristic:
- the ability to make quick and accurate measurements
- high measurement resolution of 0.01°
- the measurement is performed with an accuracy of 0.1°
- HOLD function allows you to keep the current measurement on the display
- The REF function allows you to zero the protractor at any position and perform a reference measurement
- automatically turns off the device after approx. 3 minutes
- 4 measurement units: degrees, slope in %, mm/m, in/ft
- the protractor base is equipped with a magnet making it easier to take measurements on steel elements
Technical Specifications:
Rated voltage: 3V dc
Power supply: 2 x AAA battery (not included)
Range of the measured angle: 4×90°C
Measurement resolution: 0.05°
Accuracy of the measured angle: 0.1°
Reference measurement: yes, ZERO/REF function
Saving the current measurement on the display: yes, HOLD function
Operating temperature: 0 – 40°C
